2210 Switch Series

L2 POE+ MANAGED 2210 SWITCH SERIES

The L2 PoE+ Managed 2210 Switches Series are high performance, next-generation access switches designed for carrier networks, IP metropolitan infrastructure, and enterprise-class deployments. Built on a powerful hardware architecture and driven by the advanced WDOS operating system, the 2210 Series delivers reliable switching performance, high-density PoE+ power output, and intelligent traffic processing to support large-scale and bandwidth-intensive network environments.

WD9800-48CD8D front panel

WD-GS-2210-8P2S

  • PoE Ports: 8 × Gigabit Ethernet PoE/PoE+ ports
  • Console Port: 1 × Console interface
  • Uplink Ports: 2 × 100/1000M SFP fiber ports
WD9800-48CD8D rear panel

WD-GS-2210-16P2S

  • PoE Ports: 16 × Gigabit Ethernet PoE/PoE+ ports
  • Console Port: 1 × Console interface
  • Uplink Ports: 2 × 100/1000M SFP fiber ports
WD9800-40B front panel

WD-GS-2210-24P4C

  • PoE Ports: 24 × Gigabit Ethernet PoE/PoE+ ports
  • Console Port: 1 × Console interface
  • Uplink Ports: 4 × 100/1000 M SFP Combo fiber ports

Key Features

Port Protection

All ports support 6KV lightning protection along with PSE short-circuit, PoE overload, power-supply overtemperature, over-voltage, and surge-current protection to ensure stable and safe network operation.

Powerful Switching & Processing

The switch supports 802.1Q VLAN, MAC VLAN, and IP VLAN to enable flexible network segmentation. Advanced QoS delivers 8 queues with port priority, 802.1P, DSCP, and SP/WRR/WFQ scheduling. Supports IGMP v1/v2/v3 snooping for up to 256 IGMP groups and MLD v1/v2 snooping, enabling efficient Layer-2 multicast traffic management for multi-terminal HD video surveillance and video conferencing, with fast-leave functionality, integrated Layer-2 multicast querier support, and support for both Layer-2 IPv4 and Layer-2 IPv6 static multicast.

Perfect Security Mechanism

Supports IEEE 802.1x, RADIUS, and TACACS+ authentication for strong access control. Loop detection ensures stable long-term operation. Security features include VLAN port isolation, DHCP Snooping, IP+MAC+Port binding, ARP protection, IP source protection, and DoS defense. User access can be restricted by port, IP address, or MAC address to enhance network security.

Diverse Reliability Protection

L2 network management function, complete security protection mechanism, ACL/QoS policy and rich VLAN functions, easy to manage and maintain. Support multiple network redundancy protocols STP/RSTP/MSTP (<50ms), Support ERPS ring network function (convergence time<20ms) to improve link backup and network reliability to ensure uninterrupted communication of important applications. According to actual application needs, Routing address management, port management, port flow control, VLAN division, IGMP, security policy and other application service configurations are performed through Web, CLI, SNMP, Telnet and other network management methods. The shell is made of steel alloy, which has excellent industrial field environmental adaptability (including mechanical stability, climate environment adaptability, electromagnetic environment adaptability, etc.), protection level is IP40, low power consumption and no fan, 3-year warranty.

Software

SOFTWARE SPECIFICATIONS

VLAN Features
  • 4K Active VLAN
  • QinQ & Selective QinQ
  • GVRP
  • Port VLAN, Protocol VLAN
  • Voice VLAN
  • Private VLAN, IP VLAN
  • Support 802.1Q Tunneling
  • MAC VLAN
  • Spanning Tree Protocol (STP)
  • RSTP (IEEE 802.1w)
  • MSTP (IEEE 802.1s) Protocols
  • Support loop protection
  • Root bridge protection, TC protection
  • BPDU Protection
  • BPDU filtering
Link Aggregation
  • Static Link Aggregation
  • LACP
  • Algorithm based on Source/Destination MAC
  • Algorithm based on Source/Destination IP
Safety Features
  • Password protection
  • Support to restrict user access based on port number, IP address
  • MAC address Filter
  • Support HTTPS, SSL V3, TLS V1, SSH V1 V2
  • Support IP MAC PORT binding
  • ARP protection, IP source protection, DoS protection
  • Support Snooping, DHCP attack protection
  • Radius and TACACS+ Authentication
  • Loopback Detection
  • 802.1X authentication Port Based Mac Based
  • Support port security and port isolation
  • Support CPU protection function
  • Port Security
  • Guest Vlan
  • AAA
IP Routing
  • Static Routing
  • 128 Routing Table
  • DHCP Server/Client
  • DHCP Relay/Option 82
  • DHCP Snooping
  • IPv4/IPv6 Dual Stack
ERPS
  • G.8032 Ring Protection
  • <20 ms Convergence
    QOS (Quality of Service)
    • Supports 8 port queues
    • Support port priority
    • CoS 802.1P priority, DSCP priority
    • Support SP (Strict Priority)
    • WRR (Weighted Round Robin)
    • WFQ priority scheduling algorithm
    Access control
    • Support L2 (Layer 2) to L4 (Layer 4) packet filtering function
    • ACL Time Based ACL
    • Traffic statistics, Flow Control
    • Support port mirroring, RX/RX/BOTH; Many-to-1 monitor
    Multicast Features
    • IGMP v1/v2 Snooping
    • Multicast VLAN
    • MLD Snooping 256 Groups
    • Multicast filtering, packet statistics, unknown multicast Discard
    Storm suppression
    • Multicast suppression
    • Broadcast suppression
    • Unknown unicast suppression
    PoE Management
    • PoE total power limit
    • PoE Enable/Disable
    • PoE port priority
    • PoE Power Scheduling
    Management
    • Support WEB network management (HTTP, HTTPS)
    • Support CLI (Telnet, SSH V1/V2, Console)
    • Support SNMP V1/V2/V3
    • Support LLDP
    • Support CPU monitoring, Memory Monitoring
    • Support system log(SYSLOG)
    • Cable Diagnostics
    • UDLD
    • RMON 4 Groups
    • Firmware upgrade via Web/TFTP
    • Supports SNTP
    • Support IPv4/v6 Ping
    • Support Traceroute
    • SFP DDM (Digital Diagnostics Monitoring)
    Hardware

    Hardware Specifications

    Features WD-GS-2210-8P2S WD-GS-2210-16P2S WD-GS-2210-24P4C
    1 GE Ports (RJ45) 8 16 24
    SFP Ports (1G) 2 2 4 COMBO
    RAM 128 MB 128 MB 128 MB
    Flash 16 MB 16 MB 16 MB
    Backplane bandwidth 20 Gbps 36 Gbps 56 Gbps
    Forwarding Capacity 15 Mpps 29 Mpps 42 Mpps
    MAC 8K 8K 16K
    JUMBO Frame 10K 10K 10K
    Packet Buffer 4.1 MB 4.1 MB 4.1 MB
    Console 1 RJ45 Port 1 RJ45 Port 1 RJ45 Port
    RST Button 1 1 1
    Input Voltage AC:100-240V@50/60Hz, 48V-56V DC
    Idle Power 6W 8W 10W
    Max Power/Full Load 150W 240 W 400W
    PoE Max output power Single-port 30 W 30 W 30 W
    FAN - 2 2
    MTBF 200000 Hrs. 220000 Hrs. 256000 Hrs.
    Dimension (WxDxH) 330x172x44 mm 266×161×44 mm 440×160×44 mm
    Weight 1.1 kg 1.5 kg 1.8 kg
    Operating Temperature -5°C to 55°C -5°C to 55°C -5°C to 55°C
    Storage Temperature -40°C~85℃ -40°C~85℃ -40°C~85℃
    Humidity (non-condensing) 5-95% 5-95% 5-95%
    Storage humidity (RH without condensation) 0%~95% 0%~95% 0%~95%
