INDUSTRIAL GIGABIT MANAGED POE / POE+ SWITCH SERIES

All models integrate 6kV lightning immunity, PSE short-circuit protection, PoE overload prevention, and EMC Class 4 surge/ESD resistance. The rugged fan less metal housing supports stable operation from –40°C to 85°C, delivering long-term reliability in harsh industrial environments. This design minimizes downtime and maintenance requirements, making the switch ideal for industrial, outdoor, and mission-critical deployments.

The switch offers flexible segmentation through 802.1Q, MAC-based, and IP-based VLANs. It features a high-performance QoS engine with 8 queues using 802.1P, DSCP, and SP/WRR/WFQ scheduling. L2–L4 ACLs enable granular packet control, and full multicast support with IGMP v1/v2/v3, MLD Snooping, fast-leave, querier functionality, and IPv4/IPv6 multicast ensures smooth HD video and optimized bandwidth utilization. These capabilities provide deterministic performance for voice, video, and data traffic across enterprise and service-provider networks.

The system supports IEEE 802.1x, Radius, and Tacacs+ authentication for strong access control. Additional protection includes VLAN port isolation, DHCP Snooping, ARP guard, IP–MAC–Port binding, IP source guard, DoS protection, and loop detection. Access policies can be enforced by port, IP address, or MAC address to maintain strict network security. This multi-layered se- curity architecture protects against unauthorized access and internal or external network threats.

AI Loopback Protect delivers rapid fault recovery within 10 ms using RUN Ring technology. AI PoE automatically detects and restores unresponsive PDs, AI VLAN isolates ports to reduce broadcast storms, and AI Extend increases PoE transmission dis- tances up to 250 meters for extended surveillance and long-reach deployments. These AI-based capabilities significantly reduce manual intervention and improve network resilience in unattended environments.
